DETAILS
Platform
Synapse Carbon
Model Name
Synapse Carbon 1 RLE
Model Code
C12102U
FRAMESET
Frame
Synapse Carbon, SmartSense enabled, Proportional Response size-specific design, BSA threaded BB, flat mount brake, 12x142mm thru-axle, thru-tube internal cable routing with Switch Plate, removable fender bridge, hidden rack/fender mounts
Fork
Synapse Carbon, integrated crown race, Proportional Response size-specific design, 12x100mm thru-axle, thru-tube internal routing, hidden fender mounts
Headset
Synapse Carbon Sealed Bearing, integrated, 1-1/4"-1-1/8"
DRIVETRAIN
Rear Derailleur
Shimano Dura-Ace Di2 R9250
Front Derailleur
Shimano Dura-Ace Di2 R9250, braze-on
Shifters
Shimano Dura-Ace Di2 R9270 hydraulic disk, wireless, 2x12
Chain
Shimano Dura-Ace R9100, 12-speed
Crank
Shimano Dura-Ace R9200, 50/34
Rear Cogs
Shimano Dura-Ace R9100, 11-34, 12-speed
Bottom Bracket
Shimano Dura-Ace R9100 BSA
BRAKES
Brakes
Shimano Dura-Ace Di2 R9270 hydraulic disk, 160/160mm RT900 rotors
Brake Levers
Shimano Dura-Ace Di2 R9270 hydraulic disk
WHEELS
Rims
HollowGram 45 SL KNØT, Carbon, 20h front, 24h rear, 45mm deep, 21mm inner width, tubeless ready
Spokes
DT Swiss Aerolite, straight-pull
Tire Size
30
Wheel Size
700c
Hubs
(F) HollowGram KNØT, sealed bearing 12x100mm centerlock / (R) HollowGram KNØT, 12x142mm centerlock w/ DT Swiss 240 internals
Tires
Vittoria Corsa tan wall, 700x30c
Front Tire
Vittoria Corsa tan wall, 700x30c
Rear Tire
Vittoria Corsa tan wall, 700x30c
COMPONENTS
Handlebar
HollowGram SAVE SystemBar, Carbon, 8 deg. pitch adjust
Stem
HollowGram SAVE, Alloy, -6°
Grips
Fabric Knurl Bar Tape
Saddle
Fizik Tempo Argo R3, 150mm width, K:ium rails
Seatpost
HollowGram SAVE Carbon SmartSense, 27.2x350mm (48-56), 400mm (58-61)
CONNECTIVITY
Wheel Sensor
Cannondale Wheel Sensor
EXTRA
Extra 1
SmartSense with Lights and Radar, Trainer-compatible thru-axle
