Stem
Alloy Trail Stem, 1.4 inches bar bore
Saddle
Body Geometry Bridge Saddle, steel rails
Tape
Specialized Trail Grips
Handlebars
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 1.2 inches rise, 30.7 inches width
SeatPost
TranzX dropper, 1.4 inches, S1: 3.9 inches, S2: 4.9 inches, S3: 5.9 inches. S4-S5: 6.7 inches, S6- 200mm
Seat Binder
Alloy, 38.6mm
Frame
Specialized M5 premium alloy, BB height adjust, S-Sizing, internal cable routing, 5.9 inches travel, 5.8 inches spacing
Rear Hub
Alloy, sealed cartridge bearings, 12x5.8 inches thru-axle, 32h
Front Tire
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.6"
Spokes
DT Swiss Industry
Rear Tire
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5x2.6"
Rims
Specialized 29, hookless alloy, 1.2 inches inner width, tubeless ready
Front Hub
Specialized alloy front hub disk, sealed cardridge bearings, 6-bolt, 15x4.3 inches thru-axle, 32h
Inner Tubes
Standard, Presta Valve
Wiring Harness
Custom Specialized wiring harness
Charger
Custom charger, 42V4A w/ Rosenberger plug, 100-240V
Motor
Specialized 2.2 Custom Rx Trail Tuned Motor
Battery
Specialized M3-700, Integrated battery, 700Wh
UI/Remote
Specialized TCU, 10-LED State of charge, 3-LED Ride Mode display, ANT+/Bluetooth®, w/Handlebar remote
Crankset
Praxis Forged/Custom Offset/ISIS Spindle Interface, 160mm
Cassette
SRAM NX Eagle, 12-speed, 11-50t
Chain
SRAM NX Eagle, 12-speed
Shift Levers
SRAM SX Eagle, 12-speed
Rear Derailleur
SRAM SX Eagle, 12-speed
Chainrings
SRAM X-Sync Eagle, 104 BCD, 34t, steel
Fork
RockShox 35 Silver, 1.4 inches stanchion, Turnkey damper, S1: 5.9 inches travel, S2-S6: 6.3 inches travel
Rear Shock
RockShox Deluxe Select R, rebound adjust, S1: 52.5x8.3 inches, S2-S6: 55x210mm
Rear Brake
SRAM Guide RE, 200mm
Front Brake
SRAM Guide RE, S1-S3: 7.9 inches, S4-S6: 220mm
Weight
52.5 lbs (52 lb, 7.9 oz)
Weight Size
S4
